| # | Model | Pressure | Shell | Flow Rate m³/min | Port size |
|---|---|---|---|---|---|
| 1 | DDH55+ | 20 bar | Aluminum | 3.3 | G1/2 |
| 2 | DDH200+ | 20 bar | Aluminum | 12.0 | G1 1/2 |
| 3 | DDH160+ | 50 bar | Aluminum | 2.7 | G1/4 |
| 4 | DDH550+ | 50 bar | Aluminum | 9.2 | G3/4 |
| 5 | DDH340+ | 50 bar | Stainless steel | 5.7 | G1/2 |
| 6 | DDH315+ | 100 bar | Stainless steel | 5.3 | G1/2 |
| 7 | DDH255+ | 350 bar | Stainless steel | 4.3 | G1/2 |
| 8 | DDH510+ | 350 bar | Stainless steel | 8.5 | G3/4 |
| # | Attribute Name | Attribute Value |
|---|---|---|
| 1 | Type | High Pressure Compressed Air Filter |
| 2 | Working Pressure | 20 / 50 / 100 / 350 bar |
| 3 | Filtration Grade | 0.01 µm |
| 4 | Residual Oil Content | ≤0.01 mg/m³ |
| 5 | Air Flow Capacity | 2.7-12 m³/min (45-200 l/s) |
| 6 | Connection Thread | G1/4 to G1 1/2 |
| 7 | Housing Material | Aluminum (20/50B ALU);Stainless Steel (50B SS/100B/350B) |
| 8 | Suitable For | Breathing Air, Gas Bottling, High Pressure Systems, PE Bottle Blowing |
| 9 | Differential Pressure Indicator | Not Configured (per IAT spec) |
| 10 | Certification | ISO 8573-1:2010 Class 2 |
