Performance
|
|
XAS 88
|
XAS 98
|
|
Working pressure
|
bar
|
7.0
|
7.0
|
|
|
psi
|
100
|
100
|
|
Free air delivery
|
m3/min
|
5.0
|
5.3
|
|
|
cfm
|
175
|
188
|
|
Oil volume of air compressor
|
L
|
9
|
9
|
|
Exhaust valve
|
|
3*G3/4
|
3*G3/4
|
|
Volume of diesel tank
|
L
|
60
|
60
|
|
Sound power level (Lw @2000/14/EC)
|
dB(A)
|
98
|
101
|
|
Emission standard
|
|
|
GIV
|
|
Engine
|
|
|
|
|
Brand
|
|
Kubota
|
Kubota
|
|
Model
|
|
V 1505 T
|
V 1505 T
|
|
Number of cylinders
|
|
4
|
4
|
|
Rated power
|
kW
|
33
|
33
|
|
Full load speed
|
rpm
|
3,000
|
3,000
|
|
Unload speed
|
rpm
|
1,850
|
1,850
|
|
Oil volume
|
L
|
5.5
|
5.5
|
|
Cooling system volume
|
L
|
7.5
|
7.5
|
|
Overall dimensions
|
|
|
|
|
Box-type dimensions (length*width*height)
|
mm
|
1940*1180*1150
|
1940*1200*1240
|
|
Box-type weight
|
kg
|
650
|
785
|
|
Trailer-type dimensions (length*width*height)
|
mm
|
2290*1350*1400
|
2960*1350*1420
|
|
Trailer-type weight
|
kg
|
750
|
785
|
