Reciprocating Air Compressors
Ingersoll Rand has designed reciprocating single stage air compressors and two stage air compressors to last a lifetime — Thanks to quick, easy maintenance with renewable components. Easy access to the pump components in our reciprocating compressors allows for routine maintenance and replacement of parts like the individually cast cylinders, the piston wear-sleeves, and the 15,000-hour bearings. Easy reciprocating air compressor component replacement lets you amortize your initial capital cost over a much longer equipment life span, for a superior payback on your investment.
Two-stage Compression Piston Air Compressor
Description
-Heavy-duty cast iron cylinder
-High-efficiency motor -Durable components -Built-in thermal relay (single phase) -Fully enclosed mesh belt guard -TEFC, protection level IP54, insulation level F (three phase) -Gas storage tank certified by national standards
-High-speed and reliable magnetic starter -Standard intercooler -Direct start (3hp-15hp) -Star-delta start (20hp-30hp)
-FF model standard: SDS starter, low oil level switch, aftercooler
-FF model standard: SDS starter, low oil level switch, aftercooler
-Durable components -Fully enclosed mesh belt guard -Standard certified air tank -Standard intercooler
|
Model
|
Power
|
Capacity
(0.86Mpa)
|
Speed
|
Power Supply
|
Tank
|
Dimension
|
Weight
|
|
|
HP
|
kW
|
m3/min
|
R/min
|
V/Ph/Hz/Pole
|
L
|
mm
|
kg
|
|
|
2340B3/8
|
3
|
2
|
0.27
|
1100
|
380-415V/3ph/50Hz/4P
|
80
|
1220X560X820
|
170
|
|
2475K5/8
|
5.5
|
4
|
0.49
|
1060
|
380-415V/3ph/50Hz/4P
|
150
|
1550x600x900
|
220
|
|
2475K7/8
|
7.5
|
6
|
0.61
|
1344
|
380-415V/3ph/50Hz/2P
|
150
|
1550x600x900
|
240
|
|
2545K7/8
|
7.5
|
6
|
0.71
|
765
|
380-415V/3ph/50Hz/4P
|
150
|
1550X650X1080
|
269
|
|
2545K10/8
|
10
|
7
|
0.97
|
1025
|
380-415V/3ph/50Hz/4P
|
150
|
1550X650X1080
|
274
|
|
12 barg/Horizontal Tank
|
||||||||
|
2340K3/12
|
3
|
2.24
|
0.27
|
1100
|
380V/3ph/50Hz/4P
|
150
|
1440×550×970
|
223
|
|
2475K5/12
|
5.5
|
4.10
|
0.48
|
1060
|
380-415V/3ph/50Hz/4P
|
150
|
1440×500×1050
|
245
|
|
2475K7/12
|
7.5
|
5.60
|
0.60
|
1344
|
380-415V/3ph/50Hz/2P
|
150
|
1440×500×1050
|
250
|
|
2545C7/12
|
7.5
|
5.60
|
0.70
|
765
|
380-415V/3ph/50Hz/4P
|
230
|
1740×620×1130
|
355
|
|
2545C10/12
|
10
|
7.46
|
0.96
|
1025
|
380-415V/3ph/50Hz/4P
|
230
|
1740×620×1130
|
374
|
|
7100D15/12
|
15
|
11.19
|
1.32
|
1030
|
380-415V/3ph/50Hz/4P
|
303
|
1890×880×1325
|
583
|
|
7100D15/12
|
15
|
11.19
|
1.32
|
1030
|
380-415V/3ph/50Hz/4P
|
303
|
1890×880×1325
|
583
|
|
7100D15/12-FF
|
15
|
11.19
|
1.32
|
1030
|
380-415V/3ph/50Hz/4P
|
303
|
1890×880×1325
|
633
|
|
12 barg/Vertical Tank
|
||||||||
|
2340L3/12
|
3
|
2.24
|
0.27
|
1100
|
380V/3ph/50Hz/4P
|
230
|
860×540×1850
|
257
|
|
2545N7/12
|
7.5
|
5.60
|
0.70
|
765
|
380-415V/3ph/50Hz/4P
|
303
|
1050×640×2000
|
372
|
|
2545N10/12
|
10
|
7.46
|
0.96
|
1025
|
380-415V/3ph/50Hz/4P
|
303
|
1050×640×2000
|
372
|
|
18 barg/Horizontal Tank
|
||||||||
|
H2340K3/18
|
3
|
2.24
|
0.25
|
1040
|
380V/3ph/50Hz/4P
|
150
|
1440×550×970
|
223
|
|
H2475K5/18
|
5.5
|
4.10
|
0.39
|
910
|
380V/3ph/50Hz/4P
|
150
|
1440x540x1000
|
250
|
|
H2545C7/18
|
7.5
|
5.60
|
0.54
|
585
|
380-415V/3ph/50Hz/4P
|
230
|
1740×620×1170
|
374
|
|
H7100D10/18
|
10
|
7.46
|
0.93
|
692
|
380-415V/3ph/50Hz/4P
|
303
|
1890×880×1325
|
583
|
|
H15TE15/18
|
15
|
11.19
|
1.30
|
624
|
380-415V/3ph/50Hz/4P
|
445
|
1950×1100×1550
|
750
|
|
H15TE15/18-AC
|
15
|
11.19
|
1.30
|
700
|
380-415V/3ph/50Hz/4P
|
445
|
1950×1100×1550
|
780
|
|
H15TE20/18
|
20
|
14.92
|
1.64
|
835
|
380-415V/3ph/50Hz/4P
|
445
|
1950×1100×1550
|
770
|
|
H15TE20/18-AC
|
20
|
14.92
|
1.64
|
900
|
380-415V/3ph/50Hz/4P
|
445
|
1950×1100×1550
|
790
|
